GTKL71U

3 Star Standard+ Builder Series

  • Technology :

    Inverter

  • Star Rating :

  • Capacity :

    7.1 kW (2 TR)

  • Compressor Warranty :

    10 Yrs

  • PCB Warranty :

    5 Yrs

Feel the chill this summer with Daikin’s GTKL series. Experience uninterrupted cooling with exceptional features like Indoor Quiet Operation, Power-Airflow Dual Flaps, Power Chill Operation, Good Sleep Off Timer and many more.

Salient Features

10 Years Warranty on Compressor

Enjoy long term assurance with 10 Years of peaceful cooling at your house. Daikin provides you tension-free comfort for a decade with a warranty on your air conditioning system's compressor.

5 Years Warranty On PCB

Want additional peace of mind? With Daikin's 5 year warranty on PCB, make your experience more peaceful alongside extra assurance on the maintenance cost and enjoy smooth cooling of your AC in your home.

Air Throw 16* Meters (52 Feet)

With the Cross Flow Evaporator Fans, Daikin air conditioners' every product is perfected and re-perfected to ensure they deliver and carry the badge of trust. Air flow upto 16* metres (52 feet) away from the unit ensures uniform and powerful cooling.

In this * represent - Air throw given for 5.28KW (1.5 TR) capacity, may vary model to model We have to mention this for all the model

Anti Corrosion Treatment

Live a worry-free life with Daikin's Anti Corrosion Treatment. Daikin ACs come with a special coating which prevents the rusting of the copper coil, thus, ensuring a long life of your device and eliminating your trouble.

Automatic Error Code Display

In situations where your air conditioner is not performing to its optimum levels, Daikin technology ensures it reads the internal mechanism to automatically display any errors, making it easier to identify and solve.

Coanda Airflow

Make way for effective air circulation and efficient temperature distribution with Daikin’s Coanda airflow, designed to give the best air-conditioning experience. This function ensures cooling even in corners of the room by streaming cool air upwards along the ceiling, avoiding furniture or obstructions.

Cools at 52º C

Unlike most regular air conditioners that are designed to deliver cooling at 35°C, Daikin air conditioners are designed to perform at extreme ambient conditions as high as 52°C. This makes them the ideal choice for dry and tropical countries.

Dew Clean Technology

Daikin’s Dew Clean Technology auto-cleans the indoor heat exchanger unit, getting rid of bacteria, moulds and other unwanted particles. It ensures odour-free, fresh, consistent airflow at all times.

Econo Mode

Set the limit for power consumption with Daikin's ECONO mode feature. This function enables efficient operation by limiting the maximum power consumption. Taking one step towards Daikin's future innovation.

Good Sleep Off Timer

Assure comfortable sleep by preventing excessive cooling of the room with a temperature shift value setting. The set temperature increases by 0.5°C at 30-minute intervals, giving you a better experience.

Indoor Unit Quiet Operation

Your peace is here to stay with Daikin air conditioners indoor unit quiet operation. It optimises the airflow speed according to low noise level to give an uninterrupted comfort you desire. Switch on your Daikin AC and enjoy peaceful air conditioning experience.

Power Chill Operation

Cool down your home at a fast rate. Daikin's Power Chill operation cools down 20% faster as compared to the normal mode. It ensures your room temperature drops rapidly for immediate relief from the hot temperature outside.

Power-Airflow Dual Flaps

The Power-Airflow Dual Flaps along with the Crossflow Evaporator fans ensure even distribution of cool air in both small and large spaces, making sure you are comfortable at all times.

Smell Proof Operation

Daikin’s Smell Proof operation prevents unpleasant odour inside the indoor unit. This function is available in both Dry and Cool modes. Choose your ambience, as you like it with Daikin air conditioners.

Stabilizer Inside

No need to worry about voltage fluctuation. Daikin's Stabilizer Inside operation regulates voltage across a wide range of fluctuation (130V~285V) and helps ensuring smooth operations during voltage fluctuations.

Triple Display

The Triple Display feature shows 3 key optimum running features on your display panel: the percentage of power consumed at any given time, the set temperature of your room, and error codes, if any. This ensures the well-being of your system.

Wipe Clean Flat Panel

Clean flat panel with ease! The white AC panel is easy to keep clean from dust and other particles in air. A swift wipe with a clean cloth would remove dust without any hassle and struggle. Cleaning has never been this easy.

Specification

Model nameIndoor unit (IDU)GTKL71UV16T
Outdoor unit (ODU)RKLG71UV16T
Star Rating* 3 Star
Rated Power SupplyPhase/Frequency/Voltage1φ/50Hz/230V
Power Supply Intake Outdoor unit
Rated Cooling Capacity Full/Half (min. - max.)kW7.1/3.55 (2.1~7.5)
Btu/h24200/12100(7170~25590)
Cooling capacity @ 46°C%100%
Rated Power Consumption Full/Half (min. - max.)W2410/776 (400~2600)
Rated Annual Power ConsumptionkWh1372.85
Rated ISEERWh/Wh4.00
Voltage Range (Stabilizer Inside)V130~265
Operating CurrentA10.6

Indoor unit (IDU)

Panel Colour White
IDU Dimension (HxWxD)mm310x1100x 239
Package Dimension (HxWxD)330x1230x385
IDU Net Weight (Gross Weight)kg12.5 (16.5)
Airflow RateFeet3/min (cfm)635
m3/min (cmm)18
Moisture Removall/hr (Litres/Hour)3.3
Operation Sound H/MH/M/ML/L/SLdBA49/46/44/41/39/32

Outdoor unit (ODU)

ODU Dimension (HxWxD)mm595x845x300
Package Dimension (HxWxD)680x1035x410
ODU Net Weight (Gross Weight)kg36.5 (44)
Compressor Type Swing Compressor
Refrigerant R-32
Breaker SizeA20
Piping LengthCharge-Lessm10
Max. Length30
Max. Height20
Piping ConnectionGas / Liquidmm (Inch)φ15.9/φ 6.4 (5/8”/1/4”)
Operating Ambient Temperature RangeCooling (Min~Max)°C DB20~52
Measurement conditions:
cooling

Cooling capacity is based on: indoor temp. 27°C DB, 19°C WB; outdoor temp. 35°C DB, piping length 5 m.

sound

Sound levels are based on temperature conditions 1. above with 5m piping length. These are anechoic conversion values. These values are normally somewhat higher during actual operation as a result of ambient conditions.

Cooling and heating capacities above are rounded off to first decimal. 1TR (Ton of Refrigeration) = ~3.517 kilowatt.

*Star Rating mentioned above is as per norms defined by Bureau of Energy Efficiency, Ministry of Power, Government of India.
"Value given in Inch. #As per Continuing Policy of Product Innovation at Daikin, The Design, Technical Specifications, Features, Look may change without prior notice

AS A PART OF CONTINOUS DEVELOPMENT AND UPGRADATION THE PRODUCT IMAGE/ACCESSORY/FEATURE/SPECIFICATION MAY BE DIFFERENT FROM ACTUAL PRODUCT AT THE TIME OF PURCHASE.
