FTKR

Stabilizer Inside IoT Enabled Air-conditioning

Designed for smart cooling Daikin’s FTKR Series is poised to deliver smart air conditioning experience. From Power Chill operation to Voice control through Google and Alexa this power-packed machine is truly beyond imagination.

Product category:

Available in (kW):

Salient Features

Indoor unit quiet operation

Indoor unit quiet operation
This feature ensures low noise level resulting in sound sleep. It optimises the speed of the airflow according to low noise level to give you uninterrupted comfort.

Mobile App Controlled

Mobile App Controlled

Power chill operation

When the rooms needs to be cooled quickly in extreme heat, power chill ensures that the room temperature drops fast for immediate comfort.

Room Temperature Display at Indoor Unit

Room Temperature Display

Voice controlled with Alexa & Google Home

Voice controlled with Alexa & Google Home

Specification

Model name Indoor unit FTKR35TV16W FTKR50TV16U FTKR60TV16U
Outdoor unit RKR35TV16W RKR50TV16U RKR60TV16U
Power supply 1 50Hz 230V 1 50Hz 230V 1 50Hz 230V
(220-240V) (220-240V) (220-240V)
  Power supply intake Outdoor unit Outdoor unit Outdoor unit
Cooling capacity Rated Full/Half (min.~max.) kW 3.5/1.75(1.75 ~4.0) 5.0/2.5 (2.5~5.7) 6.0/3.0 (2.5~6.7)
Cooling capacity Rated Full//Half (Min.~Max.) Btu/h 11900/5970 (6000~13600) 17100/8500 (8500~19400) 20500/10240 (8500~22900)
Power consumption Rated Full/Half (min.~max.) W 999/330 (330-999) 1415/475 (475-1750) 1665/580 (580-1665)
Annual Power consumption kWh 577 824 989
ISEER / Star Rating Wh/Wh 4.70 / 5* 4.70 / 5* 4.70 / 5*
Voltage Range V 160-265 160-265 160-265
Operating current Cooling A 4.67 6.37 7.4
Indoor unit
Panel colour   White White White
Dimensions HxWxD mm 298 x 800 x 229 298 x 885 x 229 298 x 885 x 229
(Package dimensions) (375X895X325) 375 x 980 x 325 375 x 980 x 325
Weight (Gross) kg 10(14) 11(16) 11(16)
Airflow rate m3/min. 13.4(11.9) 15.4 (13.7) 16.3 (14.8)
Operation sound H/M/ML/L/SL Cooling dBA 40/36/32/29/26 45/42/40/38/35 47/45/43/40/38
Outdoor unit
Dimensions (H x W x D) mm 550 x 765 x 285 595 x 845 x 300 595 x 845 x 300
(Package dimensions) (642 x 932 x 380) (680 x 1035 x 410) (680 x 1035 x 410)
Weight (Gross) kg 32(38) 36 (44) 39(47)
Operation sound H/L Cooling dBA 51/-- 54/-- 56/--
Compressor type     1YC22DXD#A 1YC32CXD#A 1YC36DXD#A
Refrigerant (Amount)     R32(0.56kg) R32 (0.95kg) R32 (1.00kg
Breaker size A 15 20 20
Piping length Charge-less m 10 10 10
Max. length m 20 30 30
Max. height m 15 20 20
Piping connection Gas/Liquid mm 9.5/ 6.4 12.7/ 6.4 12.7/ 6.4
Operation limit Cooling oCDB 19.4~50 19.4~50 19.4~50

Measurement conditions:

  • Cooling capacity is based on: indoor temp. 27° CDB, 19° CWB; outdoor temp. 35° CDB, piping length 5 m.
  • Sound levels are based on temperature conditions 1. above with 5m piping length. These are anechoic conversion values. These values are normally somewhat higher during actual operation as a result of ambient conditions.

Cooling and heating capacities above are rounded off to first decimal. 1TR (Ton of Refrigeration) = ~3.517 kilowatt.

For the complete feature list please refer pages 54 - 58.
