FTKL

Stabilizer Inside New age of Air-conditioning

Welcome the new age of air conditioning! Loaded with salient features, Daikin’s FTKL Series redefine modern air conditioning. Some of its great features are Dust PM2.5 lamp, Econo mode, Coanda airflow, Power chill operation and more.

Product category:

  • Split Hi-Wall Air Conditioner›FTKL

Available in (kW):

Color:
White

Salient Features

Coanda airflow

Coanda airflow operation gives you the best air-conditioning experience. The powerful air draft does not fall on your head directly, but it is steered upward letting air circulate into the corners of the room creating a comfortable ambience.

Dust PM2.5 Filter

Dust PM2.5 Filter
A dust sensor detects house dust and PM 2.5 ultra fine particles approx. 2.5 pm and smaller, and the lamps indicate air quality.

Econo mode

Econo mode
This function enables efficient operation by limiting the maximum power consumption. It is useful when using the air-conditioner and other electrical devices simultaneously on a shared electrical circuit.

Indoor unit quiet operation

Indoor unit quiet operation
This feature ensures low noise level resulting in sound sleep. It optimises the speed of the airflow according to low noise level to give you uninterrupted comfort.

Power chill operation

When the rooms needs to be cooled quickly in extreme heat, power chill ensures that the room temperature drops fast for immediate comfort.

Specification

Model name Indoor unit FTKL35TV16X FTKL50TV16U /
FTKL50TV16V		 FTKL60TV16U FTKL71TV16T
Outdoor unit RKL35TV16X RKL50TV16U /
RKL50TV16V		 RKL60TV16U RKL71TV16T
Power supply 1 50Hz 230V 1 50Hz 230V 1 50Hz 230V 1 50Hz 230V
(220-240V) (220-240V) (220-240V) (220-240V)
  Power supply intake Outdoor unit Outdoor unit Outdoor unit Outdoor unit
Cooling capacity Rated Full/Half (min.~max.) kW 3.5/1.75 (1.75~3.5) 5.0/2.5 (2.5~5.0) 6.0/3.0 (2.5~6.0) 7.1/3.55 (2.1~7.5)
Cooling capacity Rated Full/Half (min.~max.) Btu/h 11900/5970
(6000~11900)		 17100/8500
(8500~17100)		 20500/10240
(8500~20500)		 24200/12113
(7200~25600)
Power consumption Rated Full/Half (min.~max.) W 1110/468 (468-1110) 1752/615 (615-1752) 1970/780 (720-1970) 2410/780 (600-3100)
Annual Power consumption kWh 732 1045 1255 1376.59
ISEER / Star Rating Wh/Wh 3.70/3* 3.70/3* 3.70/3* 3.99/3*
Voltage Range V 160-265 160-265 160-265 160-265
Operating current Cooling A 4.87 7.71 8.67 10.6
Indoor unit
Panel colour White White White White
Dimensions HxWxD mm 283 x 800 x 198 298 x 885 x 229 298 x 885 x 229 310 x 1100 x 239
(Package dimensions) mm (265 x 855 x 340) (375 x 980 x 325) (375 x 980 x 325) (330 x 1230 x 385)
Weight (Gross) kg 8 (12) 11 (16) 11 (16) 13 (18)
Airflow rate m3/min. 9.6 16.2 16.3 20.4(17.0)
Operation sound H/M/ML/L/SL Cooling dBA 40/36/32/29/26 45/42/40/38/35 47/45/43/40/38 49/47/45/42/39
Outdoor unit
Dimensions HxWxD mm 550 x 765 x 285 595 x 845 x 300 595 x 845 x 300 595 x 845 x 300
(Package dimensions) mm (642 x 932 x 380) (680 x 1035 x 410) (680 x 1035 x 410) (680 x 1035 x 410)
Weight (Gross) kg 26(33) 34 (42) 35(43) 39(47)
Operation sound H/SL Cooling dBA 51/-- 54/-- 56/-- 58/--
Compressor type   1YC22DXD#A 1YC32CXD#A 1YC32CXD#A 2YC40AXD#A
Refrigerant (Amount)   R32(0.56kg) R32(0.70kg) R32(1.00kg) R32(1.05kg)
Breaker size A 15 20 20 20
Piping length Charge-less m 10 10 10 10
Max. length m 20 20 30 30
Max. height m 15 10 20 20
Piping connection Gas/Liquid mm 9.5/ 6.4 12.7 / 6.4 12.7 / 6.4 15.9 / 6.4
Operation limit Cooling oCDB 19.4~50 19.4~50 19.4~50 19.4~50

Measurement conditions:

  • Cooling capacity is based on: indoor temp. 27° CDB, 19° CWB; outdoor temp. 35° CDB, piping length 5 m.
  • Sound levels are based on temperature conditions 1. above with 5m piping length. These are anechoic conversion values. These values are normally somewhat higher during actual operation as a result of ambient conditions.

Cooling and heating capacities above are rounded off to first decimal. 1TR (Ton of Refrigeration) = ~3.517 kilowatt.
