FTKF

Cooling Only Super Efficient Air-conditioning

Available in the capacities of 3.6, 5.0, and 6.0 kW, Dakin’s FTKF Series of air conditioners gives an unmatched air conditioning experience.

Product category:

Available in (kW):

Color:
White

Salient Features

Coanda airflow

Coanda airflow operation gives you the best air-conditioning experience. The powerful air draft does not fall on your head directly, but it is steered upward letting air circulate into the corners of the room creating a comfortable ambience.

Econo mode

This function enables efficient operation by limiting the maximum power consumption. It is useful when using the air-conditioner and other electrical devices simultaneously on a shared electrical circuit.

Good sleep off timer

Good sleep off timer offers automatic temperature increase to avoid excessive cooling. When Good sleep off operation starts, the set temperature will increase gradually by 2°C in the next 2 hours.

Indoor unit quiet operation

This feature ensures low noise level resulting in sound sleep. It optimises the speed of the airflow according to low noise level to give you uninterrupted comfort.

Power chill operation

When the rooms needs to be cooled quickly in extreme heat, power chill ensures that the room temperature drops fast for immediate comfort.

Specification

Model name Indoor unit FTKF35TV16U FTKF50TV16U FTKF60TV16U
Outdoor unit RKF35TV16U RKF50TV16U RKF60TV16U
Power supply 1 50Hz 230V 1 50Hz 230V 1 50Hz 230V
(220-240V) (220-240V) (220-240V)
  Power supply intake Outdoor unit Outdoor unit Outdoor unit
Cooling capacity Rated Full/Half (min.~max.) kW 3.62/1.81 (1.17~4.0) 5.28/2.64 (1.0~6.0) 6.0/3.0 (1.0~7.0)
Cooling capacity Rated Full/Half (min.~max.) Btu/h 12350/6175
(4000~13600)
18016/9008
(3412~20472)
20500/10240
(3400~23900)
Power consumption Rated Full/Half (min.~max.) W 822/281 (220-1300) 1290/450 (200-1700) 1665/545 (210-2250)
Annual Power consumption kWh 483 767 957
ISEER / ISEER RANK Wh/Wh 5.80 / 5* 5.33 / 5* 4.85 / 5*
Voltage Range V 160-265 130-265 130-265
Operating current Cooling A 3.8 5.8 7.4
Indoor unit
Panel colour White White White
Dimensions HxWxD mm 298 x 885 x 229 298 x 885 x 229 298 x 885 x 229
(Package dimensions) mm (375 x 980 x 325) (375 x 980 x 325) (375 x 980 x 325)
Weight (Gross) kg 11 (16) 11 (16) 11 (16)
Airflow rate m3/min. 13 16.6 16.3
Operation sound H/M/ML/L/SL Cooling dBA 40/38/35/33/31 47/45/43/37/32 47/43/39/34/30
Outdoor unit
Dimensions (H x W x D) mm 550 x 765 x 285 595 x 845 x 300 595 x 845 x 300
(Package dimensions) mm (642 x 932 x 380) (680 x 1035 x 410) (680 x 1035 x 410)
Weight (Gross) kg 32(38) 39(47) 39(47)
Operation sound H/L Cooling dBA 51/-- 54/51 56
Breaker size A 15 20 20
Piping length Charge-less m 10 10 10
Max. length m 20 30 30
Max. height m 15 20 20
Piping connection Gas/Liquid mm 9.5/ 6.4 12.7 / 6.4 12.7 / 6.4
Operation limit Cooling oCDB 10~50 10~50 10~50

Measurement conditions:

  • Cooling capacity is based on: indoor temp. 27° CDB, 19° CWB; outdoor temp. 35° CDB, piping length 5 m.
  • Sound levels are based on temperature conditions 1. above with 5m piping length. These are anechoic conversion values. These values are normally somewhat higher during actual operation as a result of ambient conditions.

Cooling and heating capacities above are rounded off to first decimal. 1TR (Ton of Refrigeration) = ~3.517 kilowatt.
