FTHT

Stabilizer Inside Dual Comfort

An all-weather air conditioner that gives the promise of ultimate air conditioning in any given situation! It is exceptionally powerful for both heating as well as cooling needs. Being a smart inverter AC, it lets you get more, save more.

Product category:

  • Split Hi-Wall Air Conditioner›FTHT

Available in (kW):

Color:
White

Salient Features

Coanda airflow

Coanda airflow operation gives you the best air-conditioning experience. The powerful air draft does not fall on your head directly, but it is steered upward letting air circulate into the corners of the room creating a comfortable ambience.

Econo mode

Econo mode
This function enables efficient operation by limiting the maximum power consumption. It is useful when using the air-conditioner and other electrical devices simultaneously on a shared electrical circuit.

Heating function till 4°C ambient

Heating function till 4°C ambient

Indoor unit quiet operation

Indoor unit quiet operation
This feature ensures low noise level resulting in sound sleep. It optimises the speed of the airflow according to low noise level to give you uninterrupted comfort.

PM2.5 filter

Traps fine particles for cleaner airflow

Specification

Model nameIndoor unitFTHT35TV16XFTHT50TV16UFTHT60TV16U
Outdoor unitRHT35TV16XRHT50TV16URHT60TV16U
Power supply1 50Hz 230V1 50Hz 230V1 50Hz 230V
(220-240V)(220-240V)(220-240V)
 Power supply intakeOutdoor unitOutdoor unitOutdoor unit
Cooling capacity Rated Full/Half (min.~max.)kW3.5/1.75 (1.75~3.5)5.0/2.5 (2.5~5.0)6.0/3.0 (2.5~6.0)
Btu/h11900/6000 (6000~1190017100/8500 (8500~17100)20500/10240 (8500~20500
Heating capacity Rated Full/Half (min.~max.)kW3.5/1.75 (1.75~3.5)5.0/2.5 (2.5~5.0)5.5/2.75(2.5~5.5)
Btu/h11900/6000 (6000~11900)17100/8500 (8500~17100)18800/9400 (8500~18800)
Power consumption Rated Full/Half (min.~max.)CoolingW1110 /468(468-1110)1850/588 (588-1850)1970/780 (588~1970)
HeatingW1110 /468(468-1110)1850/588 (588-1850)1700/700 (588~1700)
Annual Power consumptionkWh731.901046.641254.6
ISEER / Star RatingWh/Wh3.70 / 3*3.70 / 3*3.70 / 3*
Voltage RangeCoolingV160-265160-265160-265
HeatingV160-265160-265160-265
Operating currentCoolingA4.878.158.67
HeatingA4.878.157.48
Indoor unit
Panel colourWhiteWhiteWhite
Dimensions HxWxDmm283 x 800 x 198298 x 885 x 229298 x 885 x 229
(Package dimensions) 340 x 855 x 265375 x 980 x 325375 x 980 x 325
Weight (Gross)kg8 (12)11 (16)11 (16)
Airflow rate (Cooling/Heating) *1 X(Y)Coolingm3/min.9.6 (8.5)16.2 (14.3)16.3 (14.8)
Heatingm3/min.9.6 (8.5)16.2 (14.3)16.3 (14.8)
Cooling/Heating)Feet3/min (CFM)339(300)572 (505)576 (523)
Operation sound H/M/L/SLCoolingCoolingdBA40/36/32/29/2645/42/40/38/3547/45/43/40/38
HeatingdBA40/36/32/29/2645/42/40/38/3547/45/43/40/38
Outdoor unit
Dimensions HxWxDmm550 x 765 x 285595 x 845 x 300595 x 845 x 300
(Package dimensions) 642 x 932 x 380680 x 1035 x 410680 x 1035 x 410
Weight (Gross)kg27(34)35(43)36(44)
Operation sound (H)CoolingCoolingdBA515456
 HeatingdBA515456
Breaker sizeA152020
Piping lengthCharge-lessm101010
Max. lengthm203030
Max. heightm152020
Piping connectionGas/Liquidmm9.5/ 6.412.7 / 6.412.7 / 6.4
Operation limitCoolingoCDB19.4~5219.4~5219.4~52
 HeatingoCDB4~244~244~24

Measurement conditions:

  • Cooling capacity is based on: indoor temp. 27° CDB, 19° CWB; outdoor temp. 35° CDB, piping length 5 m.
  • Heating capacity is based on : Indoor temperature 20°CDB / 15°CWB ; Outdoor temperature 7°CDB / 6°CWB
  • Sound levels are based on temperature conditions 1. above with 5m piping length. These are anechoic conversion values. These values are normally somewhat higher during actual operation as a result of ambient conditions.

* X(Y) X-Air flow rate during fan operation.
Y-Air flow rate in wet (cooling) condition.

Cooling and heating capacities above are rounded off to first decimal. 1TR (Ton of Refrigeration) = ~3.517 kilowatt. For the complete feature list please refer pages 49 - 52.
