JTKJ

Stabilizer Inside Salubrious Air-conditioning

Switch to health-giving air conditioning with Daikin’s JTKJ Series. Its patented streamer discharge technology ensures that you and your loved ones enjoy a high-class air conditioning experience that would be second to none.

Product category:

  • Split Hi-Wall Air Conditioner›JTKJ

Available in (kW):

Color:
White

Salient Features

Indoor unit quiet operation

Indoor unit quiet operation
This feature ensures low noise level resulting in sound sleep. It optimises the speed of the airflow according to low noise level to give you uninterrupted comfort.

Intelligent eye

The all-new intelligent eye with its infra-red sensor detects when the room is vacant, thus, reducing power for greater efficiency. It adjusts the temperature by 2 degree Celsius for optimum efficiency. The air-conditioning function returns to full operation, when it detects human presence.

Patented Streamer Discharge

Streamer discharge reduces unpleasant smell and viruses inside the room cleaning the indoor air.

Power chill operation

When the rooms needs to be cooled quickly in extreme heat, power chill ensures that the room temperature drops fast for immediate comfort.

Room Temperature Display at Indoor Unit

Room Temperature Display

Specification

Model nameIndoor unitJTKJ35TV16UJTKJ50TV16UJTKJ60TV16U
Outdoor unitRKJ35TV16URKJ50TV16URKJ60TV16U
Power supply1 50Hz 230V1 50Hz 230V1 50Hz 230V
(220-240V)(220-240V)(220-240V)
 Power supply intakeOutdoor unitOutdoor unitOutdoor unit
Cooling capacity Rated Full/Half (min.~max.)kW3.62/1.81 (1.17~4.0)5.0/2.5 (1.0~6.0)6.0/3.0 (1.0~7.0)
Cooling capacity Rated Full/Half (min.~max.)Btu/h12350/6175
(4000~13600)		17100/8550
(3400~20500)		20500/10240
(3400~23900)
Power consumption Rated Full/Half (min.~max.)W822/281 (220-1300)1315/418 (200-1700)1665/545 (210-2250)
Annual Power consumptionkWh483744957
ISEER / Star RatingWh/Wh5.80 / 5*5.20 / 5*4.85 / 5*
Voltage RangeV160-265130-265130-265
Operating currentCoolingA3.85.87.4
Indoor unit
Panel colourWhiteWhiteWhite
Dimensions HxWxDmm298 x 885 x 229298 x 885 x 229298 x 885 x 229
(Package dimensions)mm375 x 980 x 325375 x 980 x 325375 x 980 x 325
Weight (Gross)kg11 (16)11 (16)11 (16)
Airflow rate *1 X(Y)m3/min.13 (11.9)14.5(13.7)16.3(14.8)
Feet3/min (CFM)459 (420)512(484)576(523)
Operation sound H/M/ML/L/SLCoolingdBA39/35/32/29/2642/38/34/31/2845/41/37/33/30
Outdoor unit
Dimensions (H x W x D)mm550 x 765 x 285595 x 845 x 300595 x 845 x 300
(Package dimensions)mm642 x 932 x 380680 x 1035 x 410680 x 1035 x 410
Weight (Gross)kg32(38)39(47)39(47)
Operation sound (H)CoolingdBA48/4447/4449/46
Breaker sizeA152020
Piping lengthCharge-lessm101010
Max. lengthm203030
Max. heightm152020
Piping connectionGas/Liquidmm9.5/ 6.412.7 / 6.412.7 / 6.4
Operation limitCoolingoCDB10~5210~5210~52

Measurement conditions:

  • Cooling capacity is based on: indoor temp. 27° CDB, 19° CWB; outdoor temp. 35° CDB, piping length 5 m.
  • Sound levels are based on temperature conditions 1. above with 5m piping length. These are anechoic conversion values. These values are normally somewhat higher during actual operation as a result of ambient conditions.

Cooling and heating capacities above are rounded off to first decimal. 1TR (Ton of Refrigeration) = ~3.517 kilowatt.

* X(Y) X-Air flow rate during fan operation.
Y-Air flow rate in wet (cooling) condition.

Download Brochure Enquiry Buy Now

AS A PART OF CONTINOUS DEVELOPMENT AND UPDGRADATION THE PRODUCT IMAGE/ACCESSORY/FEATURE MAY BE DIFFERENT FROM ACTUAL PRODUCT AT THE TIME OF PURCHASE.
