FTHT60

FTHT60 is an all season air conditioner that allows heating and cooling experience along with smart savings! From hot summers to cold winters, it ensures perfect temperature in your home all year long. Switch on you Daikin Ac and enjoy peaceful air conditioning experience.

Star Rating:

3 Star

Technology:

Inverter

Refrigerant:

Salient Features

Coanda airflow

Econo mode

Heating function till 4°C ambient

Indoor unit quiet operation

PM2.5 filter

Specification

Indoor unit
Model name	Indoor unit			FTHT60TV16U
Model name	Outdoor unit			RHT60TV16U
Power supply				1 50Hz 230V
Power supply				(220-240V)
	Power supply intake			Outdoor unit
Cooling capacity Rated Full/Half (min.~max.)			kW	6.0/3.0 (2.5~6.0)
Cooling capacity Rated Full/Half (min.~max.)			Btu/h	20500/10240 (8500~20500
Heating capacity Rated Full/Half (min.~max.)			kW	5.5/2.75(2.5~5.5)
Heating capacity Rated Full/Half (min.~max.)			Btu/h	18800/9400 (8500~18800)
Power consumption Rated Full/Half (min.~max.)		Cooling	W	1970/780 (588~1970)
Power consumption Rated Full/Half (min.~max.)		Heating	W	1700/700 (588~1700)
Annual Power consumption			kWh	1254.6
ISEER / Star Rating			Wh/Wh	3.70 / 3*
Voltage Range		Cooling	V	160-265
Voltage Range		Heating	V	160-265
Operating current		Cooling	A	8.67
Operating current		Heating	A	7.48
Panel colour				White
Dimensions HxWxD			mm	298 x 885 x 229
(Package dimensions)				375 x 980 x 325
Weight (Gross)			kg	11 (16)
Airflow rate (Cooling/Heating) *1 X(Y)		Cooling	m3/min.	16.3 (14.8)
		Heating	m3/min.	16.3 (14.8)
		Cooling/Heating)	Feet3/min (CFM)	576 (523)
Operation sound H/M/L/SL	Cooling	Cooling	dBA	47/45/43/40/38
Operation sound H/M/L/SL	Cooling	Heating	dBA	47/45/43/40/38
Outdoor unit
Dimensions HxWxD			mm	595 x 845 x 300
(Package dimensions)				680 x 1035 x 410
Weight (Gross)			kg	36(44)
Operation sound (H)	Cooling	Cooling	dBA	56
Operation sound (H)	Cooling	Heating	dBA	56
Breaker size			A	20
Piping length		Charge-less	m	10
		Max. length	m	30
		Max. height	m	20
Piping connection		Gas/Liquid	mm	12.7 / 6.4
Operation limit		Cooling	oCDB	19.4~52
		Heating	oCDB	4~24

Measurement conditions:

Cooling capacity is based on: indoor temp. 27° CDB, 19° CWB; outdoor temp. 35° CDB, piping length 5 m.
Heating capacity is based on : Indoor temperature 20°CDB / 15°CWB ; Outdoor temperature 7°CDB / 6°CWB
Sound levels are based on temperature conditions 1. above with 5m piping length. These are anechoic conversion values. These values are normally somewhat higher during actual operation as a result of ambient conditions.
Due to continuous R&D remote image may differ.
* X(Y) X-Air flow rate during fan operation.
Y-Air flow rate in wet (cooling) condition.

Cooling and heating capacities above are rounded off to first decimal. 1TR (Ton of Refrigeration) = ~3.517 kilowatt. For the complete feature list please refer pages 49 - 52.
