FTHT

Cooling and Heating Dual Comfort

An all-weather air conditioner that gives the promise of ultimate air conditioning in any given situation! It is exceptionally powerful for both heating as well as cooling needs. Being a smart inverter AC, it lets you get more, save more.

Product category:

Available in (kW):

Color:
White

Salient Features

Coanda airflow

Coanda airflow operation gives you the best air-conditioning experience. The powerful air draft does not fall on your head directly, but it is steered upward letting air circulate into the corners of the room creating a comfortable ambience.

Econo mode

This function enables efficient operation by limiting the maximum power consumption. It is useful when using the air-conditioner and other electrical devices simultaneously on a shared electrical circuit.

Heating function till 4°C ambient

Indoor unit quiet operation

This feature ensures low noise level resulting in sound sleep. It optimises the speed of the airflow according to low noise level to give you uninterrupted comfort.

PM2.5 filter

Traps fine particles for cleaner airflow

Specification

Model name Indoor unit FTHT35TV16X FTHT50TV16U FTHT60TV16U
Outdoor unit RHT35TV16X RHT50TV16U RHT60TV16U
Power supply 1 50Hz 230V 1 50Hz 230V 1 50Hz 230V
(220-240V) (220-240V) (220-240V)
  Power supply intake Outdoor unit Outdoor unit Outdoor unit
Cooling capacity Rated Full/Half (min.~max.) kW 3.5/1.75 (1.75~3.5) 5.0/2.5 (2.5~5.0) 6.0/3.0 (2.5~6.0)
Btu/h 11900/5970 (6000~11900) 17100/8530 (8500~17100) 20500/10240 (8500~20500)
Heating capacity Rated Full/Half (min.~max.) kW 3.5/1.75 (1.75~3.5) 5.0/2.5 (2.5~5.0) 6.0/3.0 (2.5~6.0)
Btu/h 11900/5970 (6000~11900) 17100/8530 (8500~17100) 20500/10240 (8500~20500)
Power consumption Rated Full/Half (min.~max.) Cooling W 1110 /468(468-1110) 1850/588 (588-1850) 1970/780 (780~1970)
Heating W 1110 /468(468-1110) 1850/588 (588-1850) 1970/780 (780~1970)
Annual Power consumption kWh 731.90 1046.64 1254.6
ISEER / ISEER RANK Wh/Wh 3.70/3* 3.70/3* 3.70/3*
Voltage Range Cooling V 160-265 160-265 160-265
Heating V 160-265 160-265 160-265
Operating current Cooling A 4.87 8.15 8.67
Heating A 4.87 8.15 8.67
Indoor unit
Panel colour White White White
Dimensions HxWxD mm 283 x 800 x 198 298 x 885 x 229 298 x 885 x 229
(Package dimensions)   (265 x 855 x 340) (375 x 980 x 325) (375 x 980 x 325)
Weight (Gross) kg 8 (12) 11 (16) 11 (16)
Airflow rate Cooling m3/min. 9.6 16.2 16.3
Heating m3/min. 9.6 16.2 16.3
Operation sound H/M/L/SL Cooling Cooling dBA 40/36/32/29/26 45/42/40/38/35 47/45/43/40/38
Heating dBA 40/36/32/29/26 45/42/40/38/35 47/45/43/40/38
Outdoor unit
Dimensions HxWxD mm 550 x 765 x 285 595 x 845 x 300 595 x 845 x 300
(Package dimensions)   (642 x 932 x 380) (680 x 1035 x 410) (680 x 1035 x 410)
Weight (Gross) kg 27(34) 35(43) 36(44)
Operation sound H/SL Cooling Cooling dBA 51/-- 54/-- 56/--
  Heating dBA 51/-- 54/-- 56/--
Breaker size A 15 20 20
Piping length Charge-less m 10 10 10
Max. length m 20 30 30
Max. height m 15 20 20
Piping connection Gas/Liquid mm 9.5/ 6.4 12.7 / 6.4 12.7 / 6.4
Operation limit Cooling oCDB 19.4~50 19.4~50 19.4~50
  Cooling oCDB 4~24 4~24 4~24

Measurement conditions:

  • Cooling capacity is based on: indoor temp. 27° CDB, 19° CWB; outdoor temp. 35° CDB, piping length 5 m.
  • Heating capacity is based on : Indoor temperature 20°CDB / 15°CWB ; Outdoor temperature 7°CDB / 6°CWB
  • Sound levels are based on temperature conditions 1. above with 5m piping length. These are anechoic conversion values. These values are normally somewhat higher during actual operation as a result of ambient conditions.

Cooling and heating capacities above are rounded off to first decimal. 1TR (Ton of Refrigeration) = ~3.517 kilowatt.

AS A PART OF CONTINOUS DEVELOPMENT AND UPDGRADATION THE PRODUCT IMAGE/ACCESSORY/FEATURE MAY BE DIFFERENT FROM ACTUAL PRODUCT AT THE TIME OF PURCHASE.
